TECHNICAL FEATURES
- Drive belts: Bottom and top
- Carton size adjustment: Manual
- Taping heads: Upper and lower
- Standard configuration: TAPE-350 TBB T22, TAPE-360 TBB T33, TAPE-380 TBB???
- Tape width: from 25 to 50 mm depending on the head (to be indicated when ordering)
- Tape tension: Adjustable
- Max. tape reel diameter: 360 mm
- Internal reel diameter: 76 mm
- Power supply: 380 V three-phase – 50/60 Hertz
- Installed power: 0.25 kW
- Electrical protection: IP 54
- Working temperature: + 5° C – max. +35° C
- Production: 1000 cartons/h
- Worktable height: 650 mm
- Weight: TAPE-350 TBB 152 Kg, TAPE-360TBB 173 KG, TAPE-80 TBB147 KG
- Machine dimensions (L x W x H): TAPE-350 TBB 1170 x 860 x 1750 mm, TAPE-360 TBB 1170 x 1042 x 1754, TAPE-380 TBB 1170 x 860 x 2150 mm
